Features
For over 60 years, Silverson has been providing high shear mixers.
Unlike conventional mixers that stir using only propellers or paddles, high shear mixers break down and mix solvents through shearing action, significantly shortening mixing times and preventing agglomeration.
We offer a wide range of models to suit your specific application and workspace requirements.
Inline Mixers
Inline mixers can increase process efficiency and reduce processing time by up to 90%. You can also switch applications by simply changing the workhead.
These mixers offer centrifugal pump-like performance, making them suitable not only for mixing but also for emulsifying, homogenizing, dissolving, slurry production, dispersing, particle size reduction, and more.
Benefits
- Prevents air entrainment
- Easy replacement of workheads
- Equipped with pumping capabilities
- Simple maintenance
- Sanitary design available
- Energy-efficient processing
- Quick and uniform mixing without powder lumps
- Stable emulsions and suspensions
- Particle size reduction via milling effect
- Redispersion of agglomerates
- Accelerated chemical reactions
General-Purpose Inline Mixers
Silverson’s general-purpose inline mixers can also be supplied for hazardous and aggressive chemical processing.
These units are ruggedly constructed with a simple design, making maintenance easy and minimizing process downtime.
The tip speed generated by the Silverson rotor and the associated shear forces are among the highest in their class,
allowing process times to be reduced by up to 90%. They excel in applications such as particle size reduction, emulsification, dissolution, and dispersion of agglomerates.
Inline Mixers – 50Hz Specifications
| kW | RPM | TEFV A | EExD A | TEFV B | EExD B | C | D | E | Piping Diameter | |
| 275LS | 1.5 | 3000 | 524 | 518 | 140 | 230 | 98 | 133 | 167 | 38 |
| 425LS | 4 | 3000 | 692 | 702 | 189 | 289 | 129 | 181 | 225 | 50 |
| 450LS | 7.5 | 3000 | 692 | 702 | 189 | 289 | 129 | 181 | 225 | 50 |
| 600LS | 15 | 3000 | 911 | 911 | 239 | 316 | 156 | 213 | 284 | 75 |
| 700LS | 37 | 3000 | 1227 | 1177 | 325 | 370 | 203 | 330 | 479 | 100 |
General-Purpose Inline Mixer Options
- Jacketed housings for heating or cooling
- Available in Hastelloy, titanium, or special stainless steel finishes
- High pumping capacity: 220–330,000 L/hr
Typical Applications
Asphalt production, edible oil manufacturing, drilling mud, adhesives, lubricants, pigment pastes, titanium dioxide dispersions, and more.
Additional Information
These are some of the most popular models from Silverson, but we can also accommodate custom sizes and specific applications.
Rental options are also available.
If you have any questions, requests, or would like a quotation, please feel free to contact us.
